Product Description
-
Netgear 300 Series Gigabit Ethernet Unmanaged Switches provide easy, reliable, and affordable network connectivity for home and small offices
-
With these unmanaged plug-and-play switches, you can expand your network connections to multiple devices instantly
-
Just step up to GS348 directly to avoid congestion due to stacking up lower port count switches and
be ready for future expansion
-
Auto-MDI/MDIX eliminates the need for crossover cables
-
LED indicators for ease of use
-
Energy-efficient technology for power savings
-
Fanless design for silent operation
-
Auto-negotiation for automatic connection at the highest common speed between switch and an end device
-
Non-blocking switching architecture for Maximum throughput at wire speed
-
802.1p QoS for traffic/frame prioritization
-
Plug-and-play; no setup required
-
Durable and rugged metal case
-
Ideal for small office and home networks
-
Standards-based technology ensures interoperability with any standards-based devices in the existing network
Product Specification
| Brand | Netgear |
| Product Type | POE Switch |
| Product Model | GS348 |
| Features | |
| 10/100/1000mbps Ports | 48 |
| Enclosure | Metal |
| Connector Type | Metal |
| Power On/Off Switch | No |
| Form Factor | Desktop, rack-mountable |
| Performance | |
| Bandwidth | 96 Gbps |
| Buffer Memory | 1.5 MB |
| Jumbo Frames | 9,216 bytes |
| Queue WRR (Weighted Round Robin) Ratio | 1:3:5:7:8:10:12:15 |
| Forwarding Rate (USING 64-Byte Packets) | 1,448,000 pps |
| Latency (Using 64-Byte Packets, 1 Gbps Connectivity) | < 4 μsec |
| Mac Address Table Size Poe Support | 8K |
| Auto MDI/MDI-X Cable Detection | Yes |
| Auto-Sensing Half/Full Duplex Switched Ports | Yes |
| Mean Time Between Failures (MTBF) 25° C | 1,094,297 hours |
| LEDs | |
| Per Port | Speed, Link/Activity |
| Per Device | Power |
| Quality Of Service (QOS) | |
| Energy Efficient Ethernet (IEEE 802.3az) | Yes |
| Honors DSCP (DiffServ) Tags | Yes |
| Power/Consumption | |
| DC Input/Power In | Internal (AC: 110-240V, 50/60Hz, 1.0A Maximum) |
| Power Consumption (Maximum And Standby) | 23W/8.81W |
| Heat Dissipation (Maximum And Standby) (BTU/Hr) | 78.66 BTU/ 30.13 BTU |
| Energy Efficiency | |
| Energy Efficient Ethernet (EEE) IEEE 802.3az Compliant | Yes |
| Auto Power Down | Yes |
| Short Cable Detection | No |
| Fan/Fanless | Fanless |
| Dimension | 252 x 180 x 44 mm |
| Weight | 1.31 kg |
| Warranty | 3 Years |
