Cobalt Digital 9015 Dual Monitoring Converter SDI to Analog Composite with Reclocked SDI Card

The 9015 is a dual SDI video to analog composite and reclocked SDI converter. Analog or digital output configuration can be selected as needed for a particular application.

The 9015 has two digital to analog encoders (A and B SDI to analog encoders). Each encoder has four outputs that can be user-configured as analog or reclocked SDI on an output by output basis. Composite output gain control and user configurations are adjustable using the card-edge controls.

Rear modules are sold separately as RM-9015-X for the 10-slot 8310 openGear frame, and RM20-9015-X for the 20-slot 8321 openGear frame. Also available is the RM20-9015-A/S high density split rear module (5 BNCs per module) for the 20-slot frame.

Cobalt 9015 Features:

• Two conversions on one card (SDI-SMPTE 259M-C)
• Four user selectable composite or SDI outputs per converter
• 8-bit data path, 10-bit DAC
• Automatic configuration NTSC/PAL
• Built-in color bar generator (analog outputs only)
• Video gain control accessible on card edge
• Color encoding user selectable to B&W
• Data-lock indicator
• VBI blanking on/off
• Remote control/monitoring via DashBoard software or OGCP-9000 remote control panel
• Five year warranty

Cobalt 9015 Specifications:

• Input: (2) 270 Mbit SMPTE 259M-C
• Output: 8 outputs: 4 on A converter and 4 on B converter
• Digital Output: Up to 4 per converter, user selectable
• Analog Output: Up to 4 per converter, user selectable
• Setup: User selectable on/off for NTSC
• Power: 5 watts
• Indicators: Two data lock indicators (one per converter)
